Turbomix Plus Gypsum Plaster Machine

Turbomix Plus Gypsum Plaster Machine General Information

Turbomix Plus gypsum plaster machine is designed for professionals seeking speed, efficiency and consistent quality on every construction site. Turbomix Plus is engineered to handle all types of gypsum based plasters. It ensures perfect mixing, pumping and spraying, helping you save time and labor costs.

Powerful. High Performance. Reliable.

Turbomix Plus gypsum plaster machine delivers optimal efficiency even under the toughest conditions, thanks to its high performance motor, robust pump system and advanced control panel. Its chassis features an ergonomic design, easy to clean components and is built to withstand continuous use.

Key Features:

• Suitable for all gypsum based ready mix dry plasters
• High efficiency mixing and spraying system
• User friendly digital control panel
• Quick setup and easy maintenance
• Sturdy structure for mobility on construction sites

Whether you're working on interior walls, ceilings or large scale plastering projects, Turbomix Plus is your best partner for professional plaster applications.

Technical Specifications

• Pumping capacity: 27 l/min
• Pumping capacity (with a different pump): 32 l/min
• Stator rotor set: D6-3, D7-2.5, D8-2
• Pumping pressure: 30 bar
• Pumping distance (horizontal): 40 m (max)
• Power supply: 380 V, 50 Hz
• Pumping motor: 5.50 kW
• Mixing motor: 0.55 kW
• Electrical cable: 5*4 mm² TTR, 25 m
• Protection fuse: 3*32 A
• Water pump: 0.50 HP
• Water connection: 3/4"
• Compressor: 0.90 kW, 250 l/min, 6 bar
• Hopper capacity: 150 l
• Length: 1250 mm
• Width: 750 mm
• Height: 1620 mm
• Transport height: 950 mm
• Weight: 320 kg

Standard equipment

• Stator rotor set: D6-3
• Mortar hose: 40 bar, Ø 25 mm, 15 m, coupling
• Mortar hose gasket: 25 mm, 2 piece
• Air hose: Ø 10 mm, 16 m, geka coupling
• Water hose: 3/4", 5 m
• Water pump: 0.50 HP
• Flowmeter: 150 - 1500 l/min
• Spray gun: Ø 25 mm, Nozzle 14 mm
• Nozzle: 14 mm, 1 piece
• Electrical cable: 5*4 mm² TTR, 25 m
• Sponge ball: Ø 30 mm, 2 piece
• Compressor: 0.90 kW, 250 l/min, 6 bar
• Control panel
• Cleaning rod
• Mixer shaft
• Manual rotor dismantling apparatus

Application Areas

It is suitable for use with factory made dry pre mixed pumpable mortars of the types listed below:

• Gypsum based mortars
• Injection mortars
• Reinforcement and adhesive mortars
• Self spread screeds
• Lime - gypsum mortars
• Cement mortars
• Lime mortars
• Lime - cement mortars
• Fango materials
• Insulation plasters
• Embedment mortars
• Exterior base coat plasters
• Surface screeds
• Wall mortars
• Premix mortars (Pre mixed bag)
• Insulation materials
